Window Wall
Smart integration for seamless performance
- Non thermal-break system, 4 sides sub-frame
- The depth of aluminum frame: 100mm (3-15/16''), the thickness of aluminum frame: 2mm (1/13'') to 3mm (2/17'')
- Aluminum Alloy 6063-T5 & 6063-T6
- Powder coating (non metallic or metallic) or Anodise ED
- Monolithic glass, Laminated glass or Insulating Glass with the thickness 6mm (5/21'') to 33.52mm (1-5/16'').
- Four (4) Sided Structural Glazing by glazing beads.
- EPDM or Santoprene material
- Stainless Steel A2-70 & A4-70
±1500 Pa to ±3000 Pa (depend on the size of panel)
- Not exceed 1.6 L/m2.s at pressure ±150Pa
- No water leakage at minimum pressure +450Pa
- No water leakage at pressure 225Pa - 450Pa in 5 minutes
- No water leakage at pressure 300Pa - 600Pa in 5 minutes
- No water leakage at pressure 450Pa - 900Pa in 5 minutes
Up to ±4500 Pa (depend on the size of panel)
- Seismic at serviceability limit state: ±10 mm for 10 cycles
- Seismic at ultimate limit state: ±20 mm for 10 cycles
- Minimum STC 30 (depend on the glass configuration and thickness)
The high-rise buildings, the commercial office buildings, the luxury/ high-end apartments,…
