QDP MULTIFACET
Façade system harmoniously combines slimline face widths with a high degree of functionality and excellent thermal insulation. With a face width of just 60 mm, opening units and fixed fields are indistinguishable from the outside.
On the flush, closed inside, only a slender shadow gap and the window handle betray the presence of the window vents.
Product Highlights
- Tested burglar resistance guarantees a high security standard
- Design and function are in harmony with each other through the seamless integration of window vent and load-bearing structure: opening units and fixed fields are no longer distinguishable from the outside
- Flush-fitted transition with slimline shadow gap between window vent and outer frame on the inside
Narrow face widths and floor-to-ceiling side-hung and turn/tilt opening units offer maximum transparency - Toplights and bottom lights ensure enhanced individual design options, even with mechatronic bottom-hung vents without window handles
- Tested safety barrier loading in accordance with DIN 18008: either via profile-integrated spandrel safety barriers or concealed limiting stays
Technical Information
Structural performance serviceability limit state
±2000 Pa to ±4000 PA (depend on the size of panel)
Air infiltration
Not exceed 0.0158 m3/min/m2 at pressure +300Pa for the fixed area
Static water penetration
No water leakage at pressure 300Pa - 600Pa in 5 minutes
Cyclic water penetration
No water leakage at pressure 300Pa - 600Pa in 5 minutes
Sound proofing
Minimum STC 33 (depend on the glass configuration and thickness)
